Steering Column Jacket Tube and Steering Shaft, Electrically Adjustable for 2007 Mercedes-Benz CL550
No.
Part # / Description / Price
Price
10
20
Hex Nut W Flange + Piece
Mercedes-Benz
Mercedes-Benz Description: Steering column jacket tube to console. Steering coupling to steering shaft. Bracket to steering column jacket tube.
MSRP $10.00
$7.80
MSRP $10.00
$7.80
22
Screw Mercedes-Benz
Mercedes-Benz Description: Transmission to jacket tube. M5x10. Slider at jacket tube. Frame. Fore-and-aft adjustment. Transmission, longitudinal adjustment on jacket tube.
MSRP $2.90
$2.21
MSRP $2.90
$2.21
25
MSRP $308.00
$228.16
30
Flat Head Screw Mercedes-Benz
Mercedes-Benz Description: Steering coupling to steering shaft. Bracket to jacket tube, bottom. Steering column jacket tube to console m8.
MSRP $19.50
$14.95
MSRP $19.50
$14.95
33
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: At bracket. M5x12. At console. At radiator. Fastening for lining. Fastening of cable bracket. Mounting, tank.
MSRP $1.70
$1.30
MSRP $1.70
$1.30
35
MSRP $276.00
$204.60
37
Cap Screw Mercedes-Benz
Mercedes-Benz Description: HEIGHT ADJUSTMENT MOTOR
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. ENGINE TO BRACKET
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. ENGINE TO BRACKET
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
MSRP $2.50
$1.95
MSRP $2.50
$1.95
45
Shaft Mercedes-Benz
Mercedes-Benz Notes: IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS
Description: Fore-and-aft adjustment.
55
MSRP $11.00
$8.45
65
Bearing Bushing Mercedes-Benz
Mercedes-Benz Description: Steering column jacket tube to console. Steering coupling to steering shaft. Between jacket tube and console.
110
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Jacket tube to front crossmember. M8X75
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Actuator to rear axle. Actuator mount.
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Actuator to rear axle. Actuator mount.
210
Molding Mercedes-Benz
Mercedes-Benz Description: Steering column tube adjustment switch. For jacket tube switch module. Tempomat (cruise control). Steering column switch module. To steering column tube.
MSRP $15.50
$11.83
MSRP $15.50
$11.83
250
MSRP $224.00
$166.16
260
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Handle to ratchet rod. Instrument panel to cowl.
MSRP $3.50
$2.73
MSRP $3.50
$2.73
270
MSRP $23.50
$18.20
900
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Steering column length adjustment motor m20/1. 4-pin jpt, mt3. Backrest adjuster m27/5, m28/5. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1, m28/1. 4-pin jpt, mt3. Steering column adjustment motor m 20/1, m 20/2. 4-pin jpt, mt3. Forwards/backwards steering column adjustment m20/1. 4-pin jpt, mt3. Steering column adjustment motor m20/1,m20/2. 4-pin jpt, mt3. Seat adjustment motor m27/1-3 m28/1-3. 4-pin jpt, mt3. Steering column length adjustment motor n20/1. 4-pin jpt, mt3.
MSRP $6.25
$4.81
MSRP $6.25
$4.81
905
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Data link connector x11/4. 0.5-1.0 mm2 mt3. Separation point, cockpit cable harness x35/66. 0.5-1.0 mm2 mt3. Data link connector x 11/4. 0.5-1.0 mm2 mt3. Connector diagnostics x11/22. 0.5-1.0 mm2 mt3.
MSRP $6.00
$4.68
MSRP $6.00
$4.68
905
Electric Line Mercedes-Benz
Mercedes-Benz Description: WITH GASKET. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: ...
MSRP $8.00
$6.11
MSRP $8.00
$6.11
