Heating Water Lines for Auxiliary Heater or Heater Booster for 2007 Mercedes-Benz CL550
No.
Part # / Description / Price
Price
30
MSRP $39.50
$30.55
40
MSRP $23.50
$18.20
50
Spring Hose Clamp
Mercedes-Benz
Mercedes-Benz Description: Coolant hose to engine at top. 14/12 mm. Bleed line mount. 14/12 MM. At charging air intercooler. 14/12 mm. Hose mount. 14/12 MM.
MSRP $4.50
$3.51
MSRP $4.50
$3.51
60
MSRP $21.00
$16.25
70
MSRP $75.00
$58.05
80
MSRP $8.50
$6.50
90
MSRP $12.00
$9.36
120
MSRP $32.00
$24.70
120
MSRP $25.00
$19.50
120
Hose Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: Intermediate piece to valve. T-piece junction to washer fluid heater.
130
MSRP $7.50
$5.72
130
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: 28-31 mm. 26-29.2 mm. 27 mm. 26-29.2 mm.
MSRP $7.25
$5.59
MSRP $7.25
$5.59
200
210
Hose Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From pipe system to washer fluid heater. Return.
500
Hose Mercedes-Benz
Mercedes-Benz Description: Heat duct to front longitudinal memb. Chafe protection
Inside diameter: 3mm
Outside diameter: 8mm. FUEL LINE
Inside diameter: 3mm
Outside diameter: 8mm.
Inside diameter: 3mm
Outside diameter: 8mm. FUEL LINE
Inside diameter: 3mm
Outside diameter: 8mm.
905
Seal Mercedes-Benz
Mercedes-Benz Description: Fuel pump M3/3. 2.2-3.0 MM SLK2.8Leitungsquerschnitt Min/Max: 2,2-3,0mm2ELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. CIRCULATION PUMP M 13. 2.2-3.0 MM SLK2.8Leitungsquerschnitt Min/Max: 2,2-3,0mm2ELA: +Model 1 ...
MSRP $8.00
$6.10
MSRP $8.00
$6.10
910
Housing Mercedes-Benz
Mercedes-Benz Description: To pressure tank. 2-PIN MLK1.2Model 1: MLKModel 2: 1.2Slots: 2Release tool: W220 589 01 99 25. Left exhaust gas temperature sensor B16/4. 2-PIN MLK1.2Model 1: MLKModel 2: 1.2Slots: 2Release tool: W220 589 01 99 25. INJECTION NOZZLE Y129. 2-PIN MLK1.2Model ...
MSRP $8.25
$6.37
MSRP $8.25
$6.37
915
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: 0.75-1.0 MM2 MLK1.2 ELA
Leitungsquerschnitt Min/Max: 0,75-1,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 84.
Leitungsquerschnitt Min/Max: 0,75-1,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 84.
MSRP $6.50
$4.89
MSRP $6.50
$4.89
920
Housing Mercedes-Benz
Mercedes-Benz Description: Recirculating pump plug connection x 73/2. 2-pin mlk1.2model 1: mlkmodel 2: 1.2slots: 2. Recirculating pump plug connection x73/2. 2-pin mlk1.2model 1: mlkmodel 2: 1.2slots: 2. Washer nozzle hose heating r2/11. 2-pin mlk1.2model 1: mlkmodel 2: 1.2slots: 2. ...
MSRP $8.50
$6.50
MSRP $8.50
$6.50
925
Plug Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Recirculating pump plug connection x 73/2. 2-pin. Connector, front bumper frame floor assembly x 26/27. 2-pin. Washer nozzle hose heating r 2/11. 2-pin.
