Rear Axle Suspension for 2013 Mercedes-Benz GL63 AMG
No.
Part # / Description / Price
Price
5
Wheel Carrier
Mercedes-Benz
Mercedes-Benz Notes: NOT AVAILABLE; ORDER INDIVIDUAL PARTS
Description: Right, complete.
MSRP $1,350.00
$972.00
MSRP $1,350.00
$972.00
5
Wheel Carrier Mercedes-Benz
Mercedes-Benz Notes: NOT AVAILABLE; ORDER INDIVIDUAL PARTS
Description: Left, complete.
MSRP $1,170.00
$840.00
MSRP $1,170.00
$840.00
30
MSRP $165.00
$125.73
40
Bearing Snap Ring Mercedes-Benz
Mercedes-Benz Description: WHEEL HUB, LEFT
Inside diameter: 95mm
Material thickness: 3mm.
Inside diameter: 95mm
Material thickness: 3mm.
MSRP $11.50
$8.78
MSRP $11.50
$8.78
50
MSRP $220.00
$162.44
80
Bihexagonal Nut W Flange Mercedes-Benz
Mercedes-Benz Description: Rear axle to hub, left. M24x1,5. Propeller shaft to front wheel hub, left.
MSRP $14.00
$10.66
MSRP $14.00
$10.66
90
Nut With Clamping Piece Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Lower control arm to steering knuckle, left. M16. Transverse control arm at left wheel carrier.
MSRP $9.75
$7.48
MSRP $9.75
$7.48
100
MSRP $770.00
$553.20
110
Rubber Bushing Mercedes-Benz
Mercedes-Benz Notes: IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS
Description: Left control arm. Lower control arm. Transverse control arm.
120
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Description: Left control arm. Rear shock absorbers. Transverse control arm.
150
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M14X1,5X100-10.9
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
MSRP $12.50
$9.49
MSRP $12.50
$9.49
170
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: On frame-type int. M14X95
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.
190
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Bottom left transverse control arm at frame-type integral support. Left lower transverse control arm to integral carrier.
MSRP $3.70
$2.86
MSRP $3.70
$2.86
200
MSRP $350.00
$260.40
210
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Strut rod to wheel carrier, left and right. M12X1,5X85
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.
220
Window Mercedes-Benz
Mercedes-Benz Description: Strut rod to left wheel carrier. Camber struts to wheel bearing. Strut rod to wheel carrier, lh.
MSRP $8.00
$6.11
MSRP $8.00
$6.11
250
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Torque strut to frame-type integral support, left and right. M12X1,5X60
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.
MSRP $6.00
$4.55
MSRP $6.00
$4.55
300
MSRP $189.00
$140.12
300
MSRP $248.00
$183.52
310
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Upper left transverse control arm to body. M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.
MSRP $14.00
$10.92
MSRP $14.00
$10.92
350
Eccentric Screw Mercedes-Benz
Mercedes-Benz Description: Camber strut to left rear axle carrier. Camber struts to rear subframe.
MSRP $15.50
$12.03
MSRP $15.50
$12.03
360
Window Mercedes-Benz
Mercedes-Benz Description: Tie rod to rear axle carrierDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. CAMBER STRUTS TO REAR SUBFRAMEDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. TIE ROD TO REAR SUBFRAMEDi ...
MSRP $0.30
$0.22
MSRP $0.30
$0.22
400
MSRP $122.00
$92.71
480
Eccentric Screw Mercedes-Benz
Mercedes-Benz Description: Tie rod to rear-axle bracket, left and right. M12x1,5,78. Tie rod to rear subframe left. Tie rod to left rear axle carrier.
MSRP $12.00
$9.10
MSRP $12.00
$9.10
