Seat Wiring Harness for 2006 Mercedes-Benz C55 AMG
No.
Part # / Description / Price
Price
70
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness. Steering column adjustment.
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Driver seat adjustment with memory.
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Driver seat adjustment with memory.
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A535915
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
Description: Driver seat adjustment with memory.
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Driver seat adjustment with memory.
160
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
MSRP $5.00
$3.90
MSRP $5.00
$3.90
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.41
MSRP $9.50
$7.41
200
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Left seat, power adjustable with memory.
200
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Right seat, power adjustable with memory.
200
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A535915
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
Description: Right seat, power adjustable with memory.
300
600
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Crash-active head restraint, left front seat.
600
605
Plug Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. 4-PIN JPT, MT3. Motor side flap rear shelf 4-pin m49/1. 4-pin jpt, mt3. Belt feeder,left a 10. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1. M28/1. 4-pin jpt, mt3. Seat height adjustment,rear m27/2, m28/2. 4-pin jpt, mt3. Driver fore/aft seat adjustment motor m27/1. 4-pin jpt, mt3. Seat adjuster plug-connection x54. 4-pin jpt, mt3.
MSRP $6.50
$5.07
MSRP $6.50
$5.07
610
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.99
MSRP $3.90
$2.99
610
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Data link connector x11/4. 0.5-1.0 mm2 mt3. Separation point, cockpit cable harness x35/66. 0.5-1.0 mm2 mt3. Data link connector x 11/4. 0.5-1.0 mm2 mt3. Connector diagnostics x11/22. 0.5-1.0 mm2 mt3.
MSRP $6.00
$4.68
MSRP $6.00
$4.68
625
Plug Mercedes-Benz
Mercedes-Benz Description: Front door connector to frame floor system x35/1 ,x35/2. 2-pin mqsmodel 1: mqsslots: 2. Keyless-go antenna connector x1/51. 2-pin mqsmodel 1: mqsslots: 2. Separation point rear panel door x8/46*3. 2-pin mqsmodel 1: mqsslots: 2. Rear head restraint motor co ...
MSRP $4.20
$3.25
MSRP $4.20
$3.25
630
Plug Mercedes-Benz
Mercedes-Benz Description: Gold-plated. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 0.5-0.75 MM2 MQSLeitungsquerschnitt ...
MSRP $6.00
$4.55
MSRP $6.00
$4.55
645
Plug Mercedes-Benz
Mercedes-Benz Description: Plug connector digital crash input x28/24. 2-pin mqs. Crash-active head restraint triggering unit l15/1 l15/2. 2-pin mqs. Plug connection,telematics x28/24. 2-pin mqs. Front passenger crash active head restraint separating point x150/2*1. 2-pin mqs. Crash active head restraint y24/12. Y24/13. 2-pin mqs. Separation point, crash-active head restraint x150/1 (x150/2). 2-pin mqs. Driver crash active head restraint separating point x150/1. 2-pin mqs.
MSRP $2.80
$2.15
MSRP $2.80
$2.15
