Parktronic System (Pts) for 2005 Mercedes-Benz C55 AMG
No.
Part # / Description / Price
Price
100
100
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness. Parktronic system.
120
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.41
MSRP $9.50
$7.41
200
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Parktronic system (pts), floor assy.
200
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Parktronic system (pts), floor assy.
210
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Transmission control module n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Electronic transmission control n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Air brake and central locking ...
MSRP $4.90
$3.82
MSRP $4.90
$3.82
240
Plug Mercedes-Benz
Mercedes-Benz Description: Connector, interior and subharness for taillamp x18. 4-pin slk2.8. Connector sun sensor x28/26. 4-pin slk2.8. Hydraulic pump m51/1. 4-pin slk2.8. Warning element/frame floor system connector x35/27. 4-pin slk2.8. Air conditioner case. 4-pin slk2.8. Warning device. 4-pin slk2.8. For blower. 4-PIN SLK2.8. Tail lamp cable harness plugconnection x18. 4-pin slk2.8.
MSRP $6.25
$4.81
MSRP $6.25
$4.81
250
Housing Mercedes-Benz
Mercedes-Benz Description: Control unit. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5. Sam/srb control module, rear blue n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5.
model 1: mqs / mcp
model 2: 2.8
slots: 5. Sam/srb control module, rear blue n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5.
270
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Pts output stage n62. To a 210 545 01 40. Pts output stage n 62. To 210 545 13 28. To a2105450140.
280
Cover Cap Mercedes-Benz
Mercedes-Benz Description: Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.
300
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Parktronic system. 8-pin rk1.0. Connector, parktronic, front bumper x26/27. 8-pin rk1.0. Repair solution x26/27. 8-pin rk1.0. Connector, front bumper frame floor assembly. 8-pin rk1.0.
350
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: ...
MSRP $8.00
$6.11
MSRP $8.00
$6.11
370
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
MSRP $4.00
$3.12
MSRP $4.00
$3.12
380
Contact Socket Mercedes-Benz
Mercedes-Benz Description: STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
MSRP $5.75
$4.42
MSRP $5.75
$4.42
390
Round Receptacle Mercedes-Benz
Mercedes-Benz Description: 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
MSRP $8.25
$6.37
MSRP $8.25
$6.37
