Cockpit Cable Harness for 2001 Mercedes-Benz C240
No.
Part # / Description / Price
Price
100
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Cockpit cable harness.
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cockpit cable harness used with automatic air conditioner.
120
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A535915
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731
Description: Connection for upper to lower control panel.
120
150
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Cockpit switch train s6/1. 6 pin mqs. Pneumatic control unit. 6 pin mqs. Steering column adjustment motor. 6 pin mqs. Mod. Black n72/1. 6 pin mqs. Bus node roof. 6 pin mqs. Roof mounted operating unit. 6 pin mqs. Folding top actuation switch s84/10. 6 pin mqs. Connector, overhead control panel, ffsblack x25/8. 6 pin mqs. Upper control panel n72/1. 6 pin mqs.
MSRP $8.50
$6.50
MSRP $8.50
$6.50
160
Plug Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Plug connection, airbag. 10-pin elo. Intermediate connector, airbag x28/12,. 10-pin elo. Intermediate connection, airbag. 10-pin elo.
170
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Comand control panel, black. 8-pin. Ignition lock. 8-pin. Operating unit. 8-pin. Radio navigation control unit 8-polig. 8-pin. Video and control unit. 8-pin.
180
Plug Mercedes-Benz
Mercedes-Benz Description: Ignition lock. 10 pin mqs, slk2.8. N69/5. Keyless-go control unit, plug 1. 10 pin mqs, slk2.8.
190
Plug Mercedes-Benz
Mercedes-Benz Description: Ignition lock. 8-pin+2-pin. Selector lever module. 8-pin+2-pin. Gear recognition switch. 8-pin+2-pin.
210
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Stop lamp switch, black cod. A. 3-pin jpt. Radio set-antenna. 3-pin jpt. Fuse and relay box,driver 3 polig. 3-pin jpt. Antenna amplifier. 3-pin jpt. Central locking connector x35/71. 3-pin jpt. Fuse and relay box near driver's seat. 3-pin jpt. Stop light switch s9/1. 3-pin jpt. Driver's airbag. 3-pin jpt.
MSRP $5.50
$4.29
MSRP $5.50
$4.29
230
240
Plug Mercedes-Benz
Mercedes-Benz Description: Combination switch,6-pole. 6-pin. Control unit. 6-pin. Combination switch plug-connection. 6-pin.
240
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Signal acq. & actuation mod. (sam) n10/6, n10/7. 6-pin slk2.8. Combination switch. 6-pin slk2.8. N28/1. Trailer control unit. Connector: 4. 6-pin slk2.8. Steering column adjustment up/down black. 6-pin slk2.8. Control unit. 6-pin slk2.8. Electrical center. 6-pin slk2.8. Signal acquisition and actuation module n10/7. 6-pin slk2.8.
260
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Left/right entrance/ex it lamp. 2 pin jpt. Luggage compartment lamp. 2 pin jpt. Glove compartment lamp. 2 pin jpt. Glove box lamp E13/1. 2 PIN JPT. Driver and front passenger footwell lamp e17/15, e17/16. 2 pin jpt. Left exit lights. 2 pin jpt. Courtesy lamp. 2 pin jpt. Interface. 2 pin jpt. Glove compartment lighting e13/2. 2 pin jpt. Vanity mirror illumination e14/6 e14/7. 2 pin jpt.
MSRP $3.40
$2.60
MSRP $3.40
$2.60
270
Receptacle Mercedes-Benz
Mercedes-Benz Description: Door contact switch s17/1. S17/2. 3-pin. Door contact, b-pillar, left s17/3. 3-pin. Roof rack plug-in connection. 3-pin. Connector cockpit roof x18/23. 3-pin. Left front door connector x34/1. 3-pin. Left rear door contact switch S17/3,S17/4. 3-PIN. Door contact switch,left and right s17/3 / s17/4. 3-pin.
300
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Operating unit. 18-pin mqs
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
MSRP $4.50
$3.51
MSRP $4.50
$3.51
310
Housing Mercedes-Benz
Mercedes-Benz Description: Instrument cluster a1. Instrument cluster to0015454840. 18-pin instrument cluster TO A 001 545 48 40. For pin socket housing to 001 545 48 40. To 001 545 48 80.
MSRP $6.50
$5.07
MSRP $6.50
$5.07
330
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Can b voltage distributor x30/4. 22-pin.
MSRP $4.50
$3.51
MSRP $4.50
$3.51
340
Contact Support Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear. 14-pin mqs
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.
MSRP $3.70
$2.86
MSRP $3.70
$2.86
350
Housing Mercedes-Benz
Mercedes-Benz Description: Light rotary switch to2085450840. To 208 545 08 40.
MSRP $4.40
$3.38
MSRP $4.40
$3.38
510
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.41
MSRP $9.50
$7.41
510
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.46
MSRP $7.00
$5.46
520
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Tin-plated. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. GLOVE COMPARTMENT LIGHTING E13/1. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. CIGAR LIGHTER R3. 1.5 MM2 WDF2Le ...
MSRP $15.00
$11.57
MSRP $15.00
$11.57
530
Contact Spring Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$2.73
MSRP $3.50
$2.73
530
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.99
MSRP $3.90
$2.99
536
Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Repair wiring harness, steering columnmodule.
MSRP $63.00
$48.38
MSRP $63.00
$48.38
538
Plug Mercedes-Benz
Mercedes-Benz Description: Jacket tube module n80. 14 pin. Jacket column module 14-pin n80. 14 pin. Jacket tube module n 80. 14 pin. Black steering column module n80, code a. 14 pin.
MSRP $3.40
$2.60
MSRP $3.40
$2.60
538
Lock Mercedes-Benz
Mercedes-Benz Description: To a 043 545 85 28. Jacket column module 14-pin n80. Jacket tube module n 80. Steer. Column jacket tube n80.
MSRP $4.20
$3.25
MSRP $4.20
$3.25
540
Crimp Tml Socket Contact Mercedes-Benz
Mercedes-Benz Description: WITHOUT GEL, WITHOUT SEAL. 0.75-1.0 MM2 MLK1.2SLeitungsquerschnitt Min/Max: 0,75-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MLKModel 2: 1.2SRelease tool: W220 589 01 99 25Crimp tool: W220 589 04 99 12. INSULATION 1.9. 0.75-1.0 MM2 MLK1.2SLeitungsquers ...
MSRP $6.50
$5.07
MSRP $6.50
$5.07
540
Electric Line Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 0.5 MM2 MLK1.2SLeitungsquerschnitt Min/Max: 0,5mm2Oberflächenschutz PINs: Ag+NyogelELA: -Model 1: MLKModel 2: 1.2SRelease tool: W220 589 01 99 25Crimp tool: W220 589 04 99 12. WITH GEL, WITHOUT SEAL. 0.5 MM2 MLK1.2SLeitungsquerschnitt Min/M ...
MSRP $6.25
$4.81
MSRP $6.25
$4.81
550
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
MSRP $3.90
$2.99
MSRP $3.90
$2.99
550
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.77
MSRP $4.90
$3.77
570
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Warm-up sender unit,cold start valve, air-flow sensor plate contact. 0.5-1.5mm2. TO 116 540 01 81,007 545 75 28. 0.5-1.5mm2. TO 116 540 01 81/007 545 35 28. 0.5-1.5mm2. S12. 0.5-1.5mm2. TO 002 545 64 26. 002 545 82 26. 0.5-1.5mm2. Adjustment to altitude to 007 545 7528, 116 540 0181. 0.5-1.5mm2.
MSRP $3.50
$2.73
MSRP $3.50
$2.73
580
Contact Socket Mercedes-Benz
Mercedes-Benz Description: CONNECTOR TERMINAL 30 SBC FEED-IN X151. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62. CONTROL UNIT FOR REAR SEATS N25/6. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: ...
MSRP $5.00
$3.90
MSRP $5.00
$3.90
580
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
MSRP $5.00
$3.90
MSRP $5.00
$3.90
590
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 0.5 MM2 ELO
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: ELO.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: ELO.
MSRP $6.50
$5.07
MSRP $6.50
$5.07
600
Contact Socket Mercedes-Benz
Mercedes-Benz Description: STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
MSRP $5.75
$4.42
MSRP $5.75
$4.42
600
Contact Socket Mercedes-Benz
Mercedes-Benz Description: BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
MSRP $7.00
$5.33
MSRP $7.00
$5.33
610
Distributor Mercedes-Benz
Mercedes-Benz Description: Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
MSRP $37.00
$28.60
MSRP $37.00
$28.60
650
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Adapter line. Air conditioner in the rear.
998
Electric Line Mercedes-Benz
Mercedes-Benz Description: Emergency tensioning retractors front and rear. Front passenger airbag, green. Front left belt tens. R12/1. Rear left belt tensioner r12/6. Squib 2 airbag passenger side r12/5. Passenger airbag, ignition squib 2 r12/5.
MSRP $63.00
$48.38
MSRP $63.00
$48.38
998
Repair Kit Mercedes-Benz
Mercedes-Benz Description: Driver seat belt force limiter R12/27. 2-PIN. Front passenger airbag, green r12/5. 2-pin. Front passenger airbag, yellow. 2-pin. Squib 1 airbag passenger side r12/4. 2-pin. Left windowbag r12/22. 2-pin.
998
Electric Line Mercedes-Benz
Mercedes-Benz Description: Passenger airbag, ignition squib 1 r12/4. Driver seat belt force limiter R12/27. Front passenger airbag, green r12/5. Front passenger airbag, yellow. Squib 1 airbag passenger side r12/4. Left windowbag r12/22.
MSRP $59.00
$45.15
MSRP $59.00
$45.15
