Springs and Suspension, Front for 1993 Mercedes-Benz 400E
No.
Part # / Description / Price
Price
5
Front Axle Spring
Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
124.034 70 580,581 AIR CONDITIONER 7
228 ADDITIONAL HEATER 3
480 SELF-LEVELLING DEVICE 2
481 UNDERSHIELD (STEEL PLATE) 1
600 HEADLAMP WIPER/WASHER 1
.
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-74 124 321 38 04 201 321 11 84 201 321 12 84
75-81 124 321 39 04 201 321 10 84 201 321 11 84
82- 124 321 39 04 201 321 10 84 201 321 11 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS "SPORTS UNDERCARRIAGE" CODE 653
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
-72 124 321 42 04 201 321 09 84 201 321 10 84
72-79 124 321 42 04 201 321 10 84 201 321 11 84
80- 124 321 42 04 201 321 11 84 201 321 12 84
==============================================================================================================================
INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
Description: As required.
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
124.034 70 580,581 AIR CONDITIONER 7
228 ADDITIONAL HEATER 3
480 SELF-LEVELLING DEVICE 2
481 UNDERSHIELD (STEEL PLATE) 1
600 HEADLAMP WIPER/WASHER 1
.
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-74 124 321 38 04 201 321 11 84 201 321 12 84
75-81 124 321 39 04 201 321 10 84 201 321 11 84
82- 124 321 39 04 201 321 10 84 201 321 11 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS "SPORTS UNDERCARRIAGE" CODE 653
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
-72 124 321 42 04 201 321 09 84 201 321 10 84
72-79 124 321 42 04 201 321 10 84 201 321 11 84
80- 124 321 42 04 201 321 11 84 201 321 12 84
==============================================================================================================================
ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
124.034 70 580,581 AIR CONDITIONER 7
228 ADDITIONAL HEATER 3
480 SELF-LEVELLING DEVICE 2
481 UNDERSHIELD (STEEL PLATE) 1
600 HEADLAMP WIPER/WASHER 1
.
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-74 124 321 38 04 201 321 11 84 201 321 12 84
75-81 124 321 39 04 201 321 10 84 201 321 11 84
82- 124 321 39 04 201 321 10 84 201 321 11 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS "SPORTS UNDERCARRIAGE" CODE 653
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
-72 124 321 42 04 201 321 09 84 201 321 10 84
72-79 124 321 42 04 201 321 10 84 201 321 11 84
80- 124 321 42 04 201 321 11 84 201 321 12 84
==============================================================================================================================
INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
Description: As required.
11
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 1 ( 8 mm). With spring color code in blue 1 (8 mm).
MSRP $8.50
$6.50
MSRP $8.50
$6.50
11
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 3 (18 mm).
MSRP $10.00
$7.80
MSRP $10.00
$7.80
11
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 2 (13 mm). With spring color code in red 2 (13 mm).
MSRP $9.75
$7.54
MSRP $9.75
$7.54
11
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 4 (23 mm). Number of burls: 4 (32 mm).
17
Shock Absorber Mercedes-Benz
Mercedes-Benz Notes: ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
FASTENING PARTS NOT PART OF DELIVERY SPEC., PLEASE ORDER SEPARATELY
FASTENING PARTS NOT PART OF DELIVERY SPEC., PLEASE ORDER SEPARATELY
23
Rubber Bumper Mercedes-Benz
Mercedes-Benz Notes: ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
Description: Stop buffer to 201 323 36 30,....41 30,....31 30. Stop buffer to 201 320 36 30,....41 30,....31 30. To 124 320 60 30, 124 320 64 30.
MSRP $15.50
$11.96
MSRP $15.50
$11.96
23
Rubber Bumper Mercedes-Benz
Mercedes-Benz Notes: INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
Description: Stop buffer.
MSRP $16.50
$12.61
MSRP $16.50
$12.61
29
MSRP $1.40
$1.04
32
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to steering knuckle,bottom. Damper strut to steering knuckle, bottom m12x1,5x 16. Shock absorber to steering knuckle, bottom.
MSRP $4.90
$3.77
MSRP $4.90
$3.77
35
Window Mercedes-Benz
Mercedes-Benz Description: Damper strut to steering knuckle, bottom. Hydropneumatic spring leg to steering knuckle,bottom. Shock absorber to steering knuckle, bottom. Damper strut to steering knuckle,top.
MSRP $2.40
$1.82
MSRP $2.40
$1.82
47
Screw Mercedes-Benz
Mercedes-Benz Description: DAMPER STRUT TO STEERING KNUCKLE
Diameter: 14mm
Strength / hardness class: 12.9
Thread code letter: M
Thread pitch: 1,5mm. HYDROPNEUMATIC SPRING LEG TO STEERING KNUCKLE,TOP M 14X45
Diameter: 14mm
Strength / hardness class: 12.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 14mm
Strength / hardness class: 12.9
Thread code letter: M
Thread pitch: 1,5mm. HYDROPNEUMATIC SPRING LEG TO STEERING KNUCKLE,TOP M 14X45
Diameter: 14mm
Strength / hardness class: 12.9
Thread code letter: M
Thread pitch: 1,5mm.
MSRP $8.75
$6.76
MSRP $8.75
$6.76
53
Window Mercedes-Benz
Mercedes-Benz Description: Damper strut to steering knuckle,top. Hydropneumatic spring leg to steering knuckle,top.
MSRP $2.50
$1.95
MSRP $2.50
$1.95
59
Nut Mercedes-Benz
Mercedes-Benz Description: DAMPER STRUT TO STEERING KNUCKLE, BOTTOM
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 22mm.
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 22mm.
MSRP $8.50
$6.63
MSRP $8.50
$6.63
65
MSRP $70.00
$54.18
71
MSRP $3.00
$2.34
74
MSRP $3.90
$2.99
83
Washer Mercedes-Benz
Mercedes-Benz Description: DAMPER STRUT TO RUBBER MOUNTINGDiameter: 15mmInside diameter: 15mmOutside diameter: 24mmMaterial thickness: 2,5mm. SHOCK ABSORBER TO FRAMEDiameter: 15mmInside diameter: 15mmOutside diameter: 24mmMaterial thickness: 2,5mm. TO BUMPER AT TOPDiameter: 15mmInsi ...
MSRP $1.00
$0.78
MSRP $1.00
$0.78
89
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: Lower control arm to front subframe. Shock absorber to frame. Lower control arm to steering knuckle.
